Changzhou Kafurter Machinery Co., Ltd. was established in 2011, with registered capital of
10.6 million Yuan, specializing in the production of all kinds of agricultural machinery
equipmentsuch as various mowers, wood chipper, backhoe, rotary tiller and so on, is a
collection of R & D design, production, sales as one of the high-tech enterprises. The
company is located in Changzhou City, China, adjacent to Shanghai, with superior
geographical location, and convenient transportation, rich supporting resources.
Model | ATVBH |
Motor | 9.5hp/Engine speed 3600rpm |
Reach | 2300mm |
Excavation depth | 2040mm |
Digging range | 126° |
Maximum height of the backhoe with load | 1400mm |
Width of the outrigger when mounted | 2000mm |
Total width | 2000mm |
Wheels | 16’’ |
Ball Coupling | 50mm |
Weight | 466kgs |
Packaging size | 2125*990*1035mm |
Bucket | 9’’ |
Oil capacity | 14.6L |
Cylinder | 4 pcs - Cylinder Diameter & Stroke: Ø76x305mm |
System pressure | 16Mpa |
